3.6V 18650 2900mah Li ion Cell

Product Item : LNC18650-29V
Category： NMC Cells
Model: LNC18650-29V
Voltage: 3.6V
Capacity: 2900mAh
Brand: EVE
Product description：The 3.6V 18650 2900mAh Li-ion Cell offers high capacity and reliable performance for electric two-wheelers, AGVs, portable energy storage, and robots. This rechargeable battery delivers efficient ener
INQUIRY EMAIL

Product Specifications

Item	Specification
Nominal Discharge Capacity	2850mAh Charge: 0.56A, 4.20V, CCCV 56mA cut-off Discharge: 0.56A, 2.50V DC cut-off
Minimum Discharge Capacity	2800mAh Charge: 0.56A, 4.20V, CCCV 56mA cut-off Discharge: 0.56A, 2.50V DC cut-off
Nominal Voltage	3.60V
Standard Charge	CCCV, 0.56A, 4.20±0.05V, 56mA cut-off
Rapid Charge	CCCV, 1.4A, 4.20±0.05V, 140mA cut-off
Standard Discharge	DC, 0.56A, 2.50V cut-off
Max. Continuous Discharge Current	DC, 8.4A, 2.50V cut-off
Charge/Discharge Voltage Range	4.20~2.50V
Cell Weight	46.5g Max
Cell Dimensions	Height: 65.00±0.15mm Diameter: 18.35±0.10mm
Operation Temperature (Cell Surface Temperature)	Ambient Temperature Charge: 0 to 45 ℃ Discharge: -20 to 60℃ Charge Temperature: 0 to 60℃ (recommended recharge release <45℃) Discharge Temperature: -20 to 70℃ (recommended re-discharge release <60℃)
Storage Temperature (At Shipping SOC)	1 year: -20~25℃ 3 months: -20~45℃ 1 month: -20~60℃
